Dry mortar mixer production line automatic tile adhesive machine
Description:
The main components of this product line: raw material storage system, automatic weighing system, tracking system, mixing system, pneumatic system, packaging system and dedusting system. the main control system manages the production order based on the fixed formula ratio, so the production line will dosage the coarse material from the storage silos, once you have weighed automatically, the material will enter the tank with the pre-filter and agraverse mixer efficiently. ,To mix in a short period (2-3min). The well mixed material will be dumped into the holding tank, which will make the secondary mix, then down to the new automatic filling and packing machine created. The packing machine operates efficiently based on fixed time and mixer volume, increases capacity sharp, well-packed ready-made mortar will be transferred to the finished mortar area, ready for sale.
Parameter:
| model | tile adhesive machine |
| capacity | 10-12t/h |
| occupied area | 60-100m2 |
| hight | 9m |
| total power | 60-120kw |
| batch and packaging | automatic batching and automatic packaging |
| mixer type | twin sahft paddle mixer |
Raw material of dry mortar plant:
1. Cementing material: cement, lime, plaster.
2. Aggregate: yellow sand, quartz sand, limestone, dolomite, expanded perlite etc.
3. Mineral admixture: industrial byproduct, industrial slag, fly ash, pozzolana, fine silica powder etc.
4. Water-retention and thickening material.
5. Chemical additives.
Packaging
1, HS code can be supplied to you for checking importing tax in your country.
2, Standard export packaging by container, which should be applicable to international requirement.
3, Big size equipment will be fixed by steel wire, while small ones together with spare parts will be packed into wooden boxes.
4, Standard configuration: 2X40HQ container for 1 set 10t/h dry mortar plant.
Shipping
Usually by sea, sometimes by land, air.
Delivery time: 15-30 days after deposit arrived
Installation site:
Package and delivery:
Product Tags:
|
|
Automatic Tile Adhesive Making Machine Large Capacity Dry Mix Mortar Plant Images
|
